Fiber Optic Connector Module

Industrial fiber optic connector modules from JINSHANG TECH terminate plastic optical fiber (POF), hard-clad silica (H-PCF) and glass fiber for factory automation, sensing, power and transport networks. This category covers Broadcom/AVAGO HFBR Versatile Link connectors and adapters, SMA905 high-power connectors, ST, SC and FC modules, HP industrial connector kits, and POF splitter blocks.

What you will find in this category

Connector design considerations

POF and H-PCF use large cores (typically 200–2000 µm) and are terminated with crimp, cleave-and-crimp or polished ferrules rather than the epoxy-and-polish process used for glass—select the connector and bore size to match the exact fiber and cladding diameter. SMA905 and FC threads suit high vibration and high optical power; push-pull SC/LC suit high-density panels. Ferrule material (ceramic vs metal) and polish must match the application.

Typical applications

PROFIBUS/MODBUS and factory automation links, wind and solar power control, medical and laser delivery, automotive and MOST networks, sensor and detector interfaces, and AVAGO/Broadcom Versatile Link systems.

These connectors pair with the bulkheads in fiber optical adapters, the AVAGO/HFBR cords in AVAGO optical fiber cables, and the POF assemblies in POF fiber optic cable. Termination guidance is in the FAQ, or email sales@fevelectronics.com with your fiber diameter and connector type.

Field Assembly Fast Connector, SC/LC/FC, 1000 um POF

Field-assembly quick connector for 1000um POF, metal knurled body, insertion loss <0.25dB, repeatability <=0.1dB, no polishing, for FTTH.

RCPOF1000B POF Connector (Yellow, RMPOF1000 Alt)

RCPOF1000B automotive-grade yellow POF connector, alternative to RMPOF1000. For motor-car and industrial 1.0 mm plastic optical fiber links.

HP Industrial Fiber Optic Connector Kit

HP Industrial Fiber Optic Connector. High-quality fiber optic component. OEM/ODM from Changzhou Jinshang.

HPCS-SMA905 H-PCF Connector, 200/230 um, Ceramic Ferrule

HPCS-SMA905 metal connector bored for 200/230um H-PCF, ceramic ferrule, threaded coupling, for industrial and sensing optical links.

SC/UPC Blue FTTH Fiber Optic Connector for SM/MM

Blue SC/UPC FTTH field fiber optic connector, SM/MM, zirconia ferrule, 0.9/2.0/3.0mm boot, for FTTH termination. Quote on quantity.

HCS200 SMA905 230 um Hard-Clad Silica Connector

HCS200 hard-clad silica fiber jumper with SMA905 connector for 230 um fiber. Rugged SMA905 for industrial, sensor and power delivery links.

ST (BFOC) Fiber Optic Connector, 1.0 mm POF, Metal

ST (BFOC) metal fiber optic connector for 1.0mm POF, insertion loss <=0.20dB typical, 1000 mates, IEC 61754, for electrical machines.

SOURIAU RCPOF1000B Original POF Connector

Original imported SOURIAU RCPOF1000B POF connector for 1.0 mm plastic optical fiber. Industrial and automotive-grade POF plug.

SMA905 Industrial POF Patch Cord / Jumper

Industrial plastic optical fiber patch cord with SMA905 connector. Rugged metal SMA905 jumper for sensor, medical and industrial optical links.
