Sumitomo CF-1571 JIS F05 H-PCF Simplex Connector
Sumitomo CF-1571 JIS F05 H-PCF simplex optical fiber connector, SUMITOMO ELECTRIC JAPAN body for 200/230 um PCF industrial fiber.
A Sumitomo CF-1571 JIS F05 H-PCF simplex optical fiber connector for terminating 200/230 um PCF industrial fiber.
Overview
The CF-1571 is a Sumitomo JIS F05 simplex H-PCF connector in the CF connector family. Sample photos show the SUMITOMO ELECTRIC JAPAN CF-series body used on orange industrial fiber.
Features
- Sumitomo CF-1571 JIS F05 simplex connector
- For 200/230 um H-PCF / PCF fiber
- SUMITOMO ELECTRIC JAPAN body
Specifications
| Parameter | Value | Unit | Notes |
|---|---|---|---|
| Connector | Sumitomo CF-1571 | – | Per folder identity |
| Standard | JIS F05 | – | H-PCF simplex connector |
| Fiber | 200/230 um H-PCF | – | Per connector family |
Applications
Field termination of Sumitomo H-PCF simplex jumpers in industrial optical control networks.
How to Order
Send us the required quantity and the fiber to terminate. We supply the CF-1571 JIS F05 simplex connector as shown.
FAQ
How do I choose the right H-PCF / POF industrial jumper?
Match the connector family on your equipment (JIS F05/F07, Avago Versatile Link, F07-AMP or Toshiba TOCP), the fiber core (200/230 um H-PCF or 1.0 mm PMMA POF) and the required length. Send us the OEM cable part number and we will confirm compatibility.
Are these original OEM or replacement assemblies?
These are replacement industrial fiber assemblies built to match the OEM connector and fiber type shown. Original OEM markings visible on sample connectors are retained for identification; we do not claim OEM manufacturing or authorization.
