HCS200 SMA905 230 um Hard-Clad Silica Connector
HCS200 hard-clad silica fiber jumper with SMA905 connector for 230 um fiber. Rugged SMA905 for industrial, sensor and power delivery links.
This is an HCS200 hard-clad silica (H-PCF) fiber jumper terminated with an SMA905 connector for 230 um fiber. HCS200 offers higher temperature capability and bandwidth than POF while keeping a large 230 um core that is easy to couple with SMA905.
Product Overview
HCS200 is a hard-clad silica fiber (core 200 um / fluoroacrylate hard cladding 230 um) used in industrial, sensor and power-delivery links. The SMA905 metal connector gives a rugged, repeatable termination.
Because HCS200 has a 230 um OD (vs 1.0 mm POF), the SMA905 ferrule bore and assembly must be specific to this fiber – it is not interchangeable with POF SMA905.
Key Features
- HCS200 hard-clad silica fiber
- 230 um fiber OD
- SMA905 threaded metal connector
- Higher temperature than POF
- Industrial and power-delivery links
Specifications
| Parameter | Value | Unit | Notes / Conditions |
|---|---|---|---|
| Fiber type | HCS200 (hard-clad silica) | – | H-PCF |
| Fiber diameter | 230 | um | Core 200 um / cladding 230 um |
| Connector type | SMA905 (threaded) | – | Metal body |
| Ferrule diameter | 3.17 | mm | SMA standard |
| Insertion loss (typical) | <=0.2 | dB | Per supplier generic table |
| Operating temperature | -40 ~ +75 | C | Per generic table |
| Cable diameter | 2.0 / 3.0 | mm | Per generic table |
Applications
- Industrial sensor and control links
- Power and laser light delivery
- Higher-temperature optical links
- Replacement H-PCF patch cords
See our full fiber optic connector range for other connector styles and fiber sizes. Visit the home page or read the FAQ for fiber selection help.
Ordering & Customization
We supply HCS200 SMA905 jumpers to length and can combine with other end types. Send the required length and port spec for a quotation.
FAQ
Can I use a POF SMA905 connector on HCS200? No. HCS200 is 230 um hard-clad silica while POF is 1000 um plastic; the ferrule bore, assembly and polishing are different. Use the HCS200-specific SMA905 termination.
Why Choose Us
We terminate HCS200 with the correct 230 um SMA905 bore and verify loss per order, rather than substituting a POF connector.
For pricing, lead time or custom lengths, contact our sales team.
