FC Fiber Optic Adapter, FC/APC and FC/UPC Bulkhead Coupler
FC Fiber Optic Adapter. High-quality fiber optic component. OEM/ODM from Changzhou Jinshang.
The FC fiber optic adapter is a passive FC-to-FC bulkhead coupler that precisely aligns two FC plugs through a panel or enclosure wall, available in green-coded FC/APC and white-coded FC/UPC versions.
Product Overview
From the images, the adapter is a nickel-plated metal FC-FC coupler with a square mounting flange and threaded FC ports on both sides. Two finish styles are shown: one with green protective dust caps (indicating FC/APC angled polish) and one with translucent white caps (FC/UPC). It mounts into a panel cutout with the supplied hex nut.
As a passive alignment component within our fiber optic adapter range, it adds no electronics and simply holds both FC connectors centered for a low-loss, serviceable connection.
Key Features
- FC-to-FC threaded coupling on both sides
- Nickel-plated metal bulkhead body with square flange
- FC/APC (green cap) and FC/UPC (white cap) versions
- Panel-mount installation with hex retaining nut
- Passive alignment, no electronics in the optical path
- Included dust caps protect the bore before use
Technical Specifications
| Parameter | Value | Notes |
|---|---|---|
| Coupling | FC to FC | threaded both sides |
| Finish | APC (green) / UPC (white) | select by cap color |
| Body | Nickel-plated metal | square flange |
| Mounting | Bulkhead / panel | hex nut |
| Function | Passive alignment | couples two FC plugs |
| Caps | Included dust caps | remove at install |
Applications
- Patch panels and distribution frames
- Test and service fixtures
- Enclosure and equipment-wall feed-through
- Optical distribution cabinets
- Field service and re-termination points
Performance & Reliability
The adapter centers the ceramic ferrules of both FC plugs; its performance depends on connector cleanliness, correct APC/UPC matching (do not mix APC and UPC in one coupler) and a snug panel fit. Keep dust caps fitted until the link is ready to connect.
Customization & Ordering
Tell us whether you need APC or UPC, simplex or panel density, and bulkhead or flange style. We supply adapters individually or in panel sets. All assemblies are terminated, end-face inspected and individually tested before dispatch. Send your drawing, connector pair, fiber type and target volume, and our engineers will return a configuration, sample plan and lead time. Contact our sales team for OEM/ODM support.
FAQ
Q: What is the difference between the green and white versions?
A: Green caps denote FC/APC angled polish; white/translucent caps denote FC/UPC. Always mate APC to APC and UPC to UPC.
Q: Is it panel mount?
A: Yes. The square flange and hex nut allow the coupler to be secured into a panel or enclosure wall.
Q: Does the adapter amplify the signal?
A: No. It is a passive alignment coupler; it only aligns two ferrules without any electronics.
Why Choose Us
TOCP Fiber manufactures FC adapters alongside our FC connectors and HP industrial adapters. See our FAQs or email sales.
