Asahi Kasei TCV-1000 / TCV-1000W PVC POF Cable (2.2 mm)
Asahi Kasei TCV-1000 (simplex) and TCV-1000W (duplex) PMMA POF cables with PVC jacket, 1.0mm fiber / 2.2mm OD, NA 0.50, -40 to +80 C, 500m drums.
The TCV-1000 and TCV-1000W are Asahi Kasei’s PVC-jacketed PMMA POF cables, with a 1.0 mm fiber in a 2.2 mm jacket. TCV-1000 is simplex and TCV-1000W is duplex.
Product Overview
The PVC jacket gives a flexible, low-cost, general-purpose cable rated −40 to +80 °C. Where fire-smoke rules require LSZH, use the TCU series instead; TCV is the standard indoor industrial PVC option.
Optically it is the same step-index PMMA: core RI 1.49, cladding RI 1.4, NA 0.50, 500 m drums.
Key Features
- PVC jacket, −40 to +80 °C.
- TCV-1000 simplex, TCV-1000W duplex.
- 1.0 mm PMMA core in 2.2 mm jacket; NA 0.50.
- 500 m drums; cut-to-length and termination on request.
Specifications
| Parameter | Value | Unit | Notes / Conditions |
|---|---|---|---|
| Cable type | PVC-jacketed PMMA POF | – | Asahi Kasei TCV series; PVC jacket. |
| TCV-1000 fiber / OD | 1.0 / 2.2 | mm | Single 1.0mm fiber, 2.2mm PVC jacket. |
| TCV-1000W fiber / OD | 1.0 dual / 2.2 | mm | Two 1.0mm fibers (duplex). |
| Core material | PMMA | – | Asahi Kasei. |
| Jacket material | PVC | – | TCV series. |
| Core refractive index | 1.49 | – | Asahi Kasei structure. |
| Cladding refractive index | 1.4 | – | Asahi Kasei structure. |
| Numerical aperture (NA) | 0.50 | – | Asahi Kasei. |
| Operating temperature | -40 to +80 | °C | TCV series. |
| Length per drum | 500 | m | Catalogue. |
Applications
- General industrial sensor and control links.
- Machine tool and servo wiring.
- Indoor building automation.
- Point-to-point data links.
See our full POF fiber optical cable range for other diameters and jacket options.
Ordering & Customization
We supply TCV-1000 and TCV-1000W by the 500 m drum with connector termination on request. Contact sales.
FAQ
TCV or TCU for my project? Use TCV (PVC) for normal indoor industrial wiring. Use TCU (LSZH) where public-space or fire codes require low-smoke, halogen-free cable.
