8-Core OM3 LSZH Fiber Cable, 7.0 mm, 800 N
U-DQ(ZN)H 8-Core OM3 Breakout Fiber Cable, 7.0 mm Black LSZH, 800N. Eight 50/125 µm OM3 multimode fibers in robust breakout design for high-density applications. OEM/ODM from Changzhou Jinshang.
The U-DQ(ZN)H 8-core OM3 LSZH cable combines eight OM3 fibers, a black low-smoke zero-halogen jacket, a 7.0 mm body and an 800 N tensile rating for pull-intensive, safety-sensitive routes.
Product Overview
Built for multi-channel installations that need stronger pulling performance and reduced smoke/halogen emissions, it is part of our industrial fiber range for buildings and transport.
The image shows the configuration; the exact flame classification must be confirmed for the ordered cable.
Key Features
- Eight OM3 50/125 µm fibers
- 7.0 mm black LSZH jacket
- Specified 800 N tensile rating
- High-density multi-channel construction
- Custom breakout and termination options
- Low-smoke, zero-halogen materials
Technical Specifications
| Parameter | Value | Notes |
|---|---|---|
| Fiber count / type | 8 x OM3 50/125 µm | multimode |
| Outer diameter | 7.0 mm | black LSZH |
| Tensile rating | 800 N | specified |
| Jacket | LSZH | low smoke zero halogen |
| Bandwidth | OM3 | graded-index |
| Length / connectors | Custom | per RFQ |
Applications
- Industrial buildings
- Transportation infrastructure
- Equipment rooms
- Control networks
- Multi-channel optical backbones
Performance & Reliability
OM3 fibers support high-bandwidth multimode links, while the reinforced structure protects the fiber group during handling. LSZH materials improve fire-scenario emissions characteristics; exact flame classification and compliance must be confirmed for the ordered cable.
Customization & Ordering
Specify length, breakout, connectors and the required LSZH/flame class. We confirm ratings against the production lot. All assemblies are terminated, end-face inspected and individually tested before dispatch. Send your drawing, connector pair, fiber type and target volume, and our engineers will return a configuration, sample plan and lead time. Contact our sales team for OEM/ODM support.
FAQ
Q: What does LSZH mean?
A: Low-smoke zero-halogen jackets emit less smoke and no toxic halogen gases in a fire, suited to enclosed occupied spaces.
Q: What is the 800N rating?
A: It is a specified tensile/pull rating that helps the cable withstand installation pulling forces.
Q: Is the flame class certified?
A: LSZH improves emissions; confirm the exact required flame classification for your installation.
