SMA905 Industrial POF Patch Cord / Jumper
Industrial plastic optical fiber patch cord with SMA905 connector. Rugged metal SMA905 jumper for sensor, medical and industrial optical links.
This is an industrial plastic optical fiber (POF) patch cord terminated with an SMA905 metal connector. The SMA905 uses a threaded coupling nut and a 3.17 mm (1/8 in) ferrule, making it a rugged choice for sensor, medical, industrial and laser/light-guide links.
Product Overview
SMA905 is a threaded, high-retention connector widely used with large-core POF and glass fibers. The rugged metal coupling resists accidental disconnection in industrial environments.
The supplier specification table lists SMA905 alongside ST/MU/FC/LC/SC; the values relevant to this POF jumper are insertion loss, operating temperature and cable diameter.
Key Features
- SMA905 threaded metal connector
- Rugged 3.17 mm ferrule
- POF patch cord with strain relief
- High-retention coupling nut
- For sensor and industrial optical links
Specifications
| Parameter | Value | Unit | Notes / Conditions |
|---|---|---|---|
| Connector type | SMA905 (threaded) | – | Metal body |
| Ferrule diameter | 3.17 | mm | SMA standard (1/8 in) |
| Insertion loss (typical) | <=0.2 | dB | MM PC, per generic table |
| Return loss | 30 | dB | MM, per generic table |
| Operating temperature | -40 ~ +75 | C | Per generic table |
| Storage temperature | -45 ~ +85 | C | Per generic table |
| Cable diameter | 0.9 / 2.0 / 3.0 | mm | Per generic table |
Applications
- Industrial sensor optical links
- Medical and instrumentation light guides
- Laser and illumination delivery
- Rugged machine optical jumpers
See our full fiber optic connector range for other connector styles and fiber sizes. Visit the home page or read the FAQ for fiber selection help.
Ordering & Customization
We build SMA905 POF and H-PCF jumpers to length with any combination of SMA905, ST or other ends. Send the fiber size and required length for a quote.
FAQ
Is SMA905 suitable for POF or only glass fiber? SMA905 works with both large-core glass and POF fibers; the ferrule bore is matched to the actual fiber. Tell us your fiber core and outer diameter and we will supply the correct SMA905 termination.
Why Choose Us
We size the SMA905 ferrule bore to your real fiber and assemble with verified termination. The generic table values on this page apply to the connector family; we confirm per-order test results.
For pricing, lead time or custom lengths, contact our sales team.
