Duplex POF Cable, 980/1000 µm, 2.2 x 4.4 mm, UL VW-1
I-V(ZN)Y 2-Core POF Duplex Cable, 980/1000 µm, 2.2x4.4 mm Black, UL VW-1. Two plastic optical fibers in zipcord design for industrial and automotive applications. OEM/ODM from Changzhou Jinshang.
The duplex POF cable (980/1000 µm) organizes two large-core plastic optical fibers in a 2.2 x 4.4 mm black duplex profile with UL VW-1 flame reference, built for short industrial and audio links.
Product Overview
The paired construction organizes transmit and receive channels for compatible 1 mm POF transceivers. It is part of our plastic optical fiber (POF) range.
The image shows the configuration; UL status should be verified against the supplied listing record.
Key Features
- Two 980/1000 µm POF channels
- 2.2 x 4.4 mm duplex profile
- Black jacket
- UL VW-1 specification reference
- Easy handling for compatible 1 mm POF systems
- Generous alignment tolerance
Technical Specifications
| Parameter | Value | Notes |
|---|---|---|
| Fiber type | Plastic optical fiber (POF) | 980/1000 µm |
| Elements | 2 x POF | duplex |
| Profile | 2.2 x 4.4 mm | black |
| Flame | UL VW-1 reference | verify on lot |
| Core | ~1 mm large core | forgiving coupling |
| Length / connectors | Custom | per RFQ |
Applications
- Industrial controls
- Short-reach data links
- Digital audio
- Sensors and encoders
- OEM equipment wiring
Performance & Reliability
Large-core POF offers generous alignment tolerance, simple handling and immunity to electrical noise. Optical attenuation is higher than glass fiber, so usable reach depends on wavelength, source power, receiver sensitivity, connector loss and cable length. UL status should be verified against the supplied listing record.
Customization & Ordering
Specify length and the compatible 1 mm POF connectors. We confirm the UL listing status for the ordered build. All assemblies are terminated, end-face inspected and individually tested before dispatch. Send your drawing, connector pair, fiber type and target volume, and our engineers will return a configuration, sample plan and lead time. Contact our sales team for OEM/ODM support.
FAQ
Q: What is POF?
A: Plastic optical fiber uses a large ~1 mm polymer core – easy to handle and terminate, ideal for short links.
Q: How far can POF go?
A: POF has higher loss than glass, so it is best for short industrial, control and audio links rather than long backbones.
Q: What does UL VW-1 mean?
A: It is a vertical-wire flame test reference; verify the exact listing against the supplied record.
Why Choose Us
Compare with our flexible POF duplex and nylon-jacketed POF. See FAQs.
