Avago POF Cable Assembly HFBR 4501-4511
Avago HFBR-4501/4511 compatible Versatile Link fiber optic cable, POF 1mm, up to 5MBd, for industrial control power systems automation. -40°C to +85°C, up to 50m, custom lengths. Direct replacement.
The Avago POF Cable Assembly HFBR 4501-4511 is a Versatile Link patch cord built with HFBR 4511 and HFBR 4501 connectors on 980/1000 µm simplex POF, used for industrial data links, factory automation, board-to-board and rack-to-rack connections, and high-voltage isolation.
Product Overview
This is a standard and custom Avago-compatible POF patch cord using HFBR 4501Z/4511Z connectors on 980/1000 µm simplex POF with a 2.2 mm OD PE jacket (black), individually labeled and packed in a ziplock bag. It belongs to the 650 nm fiber components family and is compatible with the Avago Versatile Link family of connectors and fiber optic components, making it a one-stop choice for industrial POF links.
Key Features
- HFBR 4511 to HFBR 4501 Versatile Link connector pair
- 980/1000 µm simplex POF, 2.2 mm OD PE black jacket
- 1 mm POF core, 0.22 dB/m typical attenuation (-40 to 85 °C)
- Compatible with Avago Versatile Link family
- Standard and custom lengths; individual labeling and packing
- Immune to EMI and lightning/transient susceptibility
Technical Specifications
| Parameter | Value | Notes |
|---|---|---|
| Connectors | HFBR 4511 to HFBR 4501 | Versatile Link |
| Fiber | 980/1000 µm simplex POF | 1 mm class |
| Cable OD / jacket | 2.2 mm / PE, black | Per spec |
| Attenuation | 0.22 dB/m typical | -40 to 85 °C |
| Wavelength | 650 nm | LED POF link |
| Length | Standard or custom to order | Labeled per piece |
Applications
- Industrial data links for factory automation and plant control
- Board-to-board and rack-to-rack intra-system links
- Wind power gate drives and control/communication boards
- Medical instruments, proprietary LANs, and high-voltage isolation
Performance & Reliability
With 1 mm POF and 0.22 dB/m typical attenuation over -40 to 85 °C, the link suits short industrial runs where EMI immunity and high-voltage isolation matter. The large POF core gives high bandwidth and a tight bend radius versus glass, while snap-together Versatile Link connectors reduce installation error. Performance depends on clean end faces and correct seating.
Customization & Ordering
We supply the full range of Avago-style POF patch cords in general-purpose or high-performance (extra-low-loss) grades, with custom length and connector combinations. Pair with the HFBR 4503/4513 latching cord for other port types. Quote: sales@fevelectronics.com.
FAQ
Q: What is the difference between 4501 and 4511?
A: They are the Versatile Link plug halves (transmitter-side and receiver-side ends) on the same cord; this assembly connects HFBR 4511 to HFBR 4501. See also the HFBR 4506/4516 patch cord.
Q: Can I get extra-low-loss POF?
A: Yes, choose between standard 0.22 dB/m POF or high-performance 0.19 dB/m ultra-low-loss POF.
Q: Which machines use these links?
A: PLC and industrial field control devices (Siemens, Bachmann, Mitsubishi class), wind power converters, and medical instruments.
Why Choose Us
We are a fiber optic cable manufacturer supplying Avago HFBR compatible POF assemblies. See the Avago optical fiber cable range and FAQs, or email sales@fevelectronics.com.
